بنگل نوادا 185410-01

Ordering Information

Part Number: 185410-01

Product Name: Essential Insight.mesh ISA100 Wireless Repeater

Kit Contents: Repeater module, mounting bracket, power supply cable, quick-start guide

Spare Parts:

Antenna, 2.4 GHz whip (185410-ANT-01)

DIN-rail bracket (185410-BRKT-01)

Power supply, 24 V DC (185410-PS-01)

Technical Parameters

Wireless Standard: ISA100.11a (IEC 62734) for Bently Nevada 185410-01

Frequency: 2.4 GHz ISM band

Transmit Power: +20 dBm (100 mW) max

Receiver Sensitivity: –100 dBm typical

Coverage Range: Up to 200 m line-of-sight; ~ 30 m indoor industrial with Bently Nevada 185410-01

Data Rate: 250 kbps PHY; mesh-routed packets up to 40 kbps

Network Capacity: Supports up to 100 sensor nodes per gateway

Power Input: 24 V DC ± 10 % @ 100 mA

Power Consumption: ≤ 2.5 W peak

Antenna Connector: RP-SMA female

LED Indicators:

Power (green)

Network Link (yellow)

Mesh Health (red/green)

Environmental Ratings:

Operating Temp: –20 °C to +60 °C

Storage Temp: –40 °C to +85 °C

Humidity: ≤ 95 % RH, non-condensing

Enclosure: IP30 (indoor) with optional IP65 kit

Product function

Mesh Repeating: Receives/forwards ISA100.11a packets via Bently Nevada 185410-01 to extend coverage.

Self-Healing: Automatically optimizes parent/child links based on signal quality.

Monitoring & Diagnostics: Reports link metrics and repeater status to gateway.

Plug-and-Play: Pre-configured join key; gateway-based discovery.

Application Areas

Petrochemical & Refining: Extending coverage around furnaces/storage tanks using Bently Nevada 185410-01.

Power Generation: Mesh networks in turbine halls with Bently Nevada 185410-01 where steel impedes signals.

Mining & Metals: Wireless mesh in heavy-steel environments for vibration sensors.

Building Automation: Integrating machinery-health transmitters.

OEM Machinery Skids: Embedded repeater in packages featuring Bently Nevada 185410-01 for robust connectivity.
